Parameter Descriptions
3.15.7 15-9* Parameter Info
15-92 Defined Parameters
Range: Function:
0 [0 - 9999 ] View a list of all defined parameters
*
in the frequency converter. The list
ends with 0.
15-93 Modified Parameters
Range: Function:
0 [0 - 9999 ] View a list of the parameters that
*
have been changed from their
default setting. The list ends with 0.
Changes may not be visible until
up to 30 s after implementation.
15-98 Drive Identification
Range: Function:
0 [0 - 40 ] This parameter contains data used
*
by the MCT 10 Set-up Software.
15-99 Parameter Metadata
Array [30]
Range: Function:
0 [0 - 9999 ] This parameter contains data used
*
by the MCT 10 Set-up Software
tool.
3.16 Parameters: 16-** Main Menu - Data
Readouts
3.16.1 16-0* General Status
16-00 Control Word
Range: Function:
0 [0 - 65535 ] View the control word sent from
*
the frequency converter via the
serial communication port in hex
code.
16-01 Reference [Unit]
Range: Function:
0 Referen- [-999999 - View the present reference value
ceFeedback 999999 applied on impulse or analog basis
Unit Reference- in the unit resulting from the
*
FeedbackUnit] configuration selected in
parameter 1-00 Configuration Mode
(Hz, Nm, or RPM).
16-02 Reference [%]
Range: Function:
0 % [-200 - View the total reference. The total
*
200 %] reference is the sum of digital,
M0010001
Programming Guide
16-02 Reference [%]
Range:
16-03 Status Word
Range:
0
*
16-05 Main Actual Value [%]
Range:
0 %
*
16-09 Custom Readout
Range:
0 Custom-
ReadoutUni
t
*
3.16.2 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW
*
16-11 Power [hp]
Range:
0 hp
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
analog, preset, bus, and freeze
references, plus catch up and slow
down.
Function:
[0 - 65535 ] View the status word sent from the
frequency converter via the serial
communication port in hex code.
Function:
[-100 - View the 2-byte word sent with the
100 %] status word to the fieldbus master
reporting the main actual value.
Function:
[-999999.99 - View the user-defined readouts as
999999.99 defined in parameter 0-30 Custom
CustomRea- Readout Unit,
parameter 0-31 Custom Readout Min
doutUnit]
Value, and parameter 0-32 Custom
Readout Max Value.
Function:
[0 - 10000 Shows motor power in kW. The
kW] value shown is calculated based on
the actual motor voltage and motor
current. The value is filtered, and
therefore approximately 1.3 s may
pass from when an input value
changes to when the data readout
values change. The resolution of
readout value on fieldbus is in
10 W steps.
Function:
[0 - 10000 View the motor power in hp. The
hp] value shown is calculated based on
the actual motor voltage and motor
current. The value is filtered, and
therefore approximately 1.3 ms may
pass from when an input value
changes to when the data readout
values change.
