Analog I/O Option Mcb 109 - Danfoss VLT AQUA Drive FC 200 Programming Manual

Parameter Lists

4.1.23 Analog I/O Option MCB 109 26-**

Par. Parameter description
No. #
26-0* Analog I/O Mode
26-00 Terminal X42/1 Mode
26-01 Terminal X42/3 Mode
26-02 Terminal X42/5 Mode
26-1* Analog Input X42/1
26-10 Terminal X42/1 Low Voltage
26-11 Terminal X42/1 High Voltage
26-14 Term. X42/1 Low Ref./Feedb. Value
26-15 Term. X42/1 High Ref./Feedb. Value
26-16 Term. X42/1 Filter Time Constant
26-17 Term. X42/1 Live Zero
26-2* Analog Input X42/3
26-20 Terminal X42/3 Low Voltage
26-21 Terminal X42/3 High Voltage
26-24 Term. X42/3 Low Ref./Feedb. Value
26-25 Term. X42/3 High Ref./Feedb. Value
26-26 Term. X42/3 Filter Time Constant
26-27 Term. X42/3 Live Zero
26-3* Analog Input X42/5
26-30 Terminal X42/5 Low Voltage
26-31 Terminal X42/5 High Voltage
26-34 Term. X42/5 Low Ref./Feedb. Value
26-35 Term. X42/5 High Ref./Feedb. Value
26-36 Term. X42/5 Filter Time Constant
26-37 Term. X42/5 Live Zero
26-4* Analog Out X42/7
26-40 Terminal X42/7 Output
26-41 Terminal X42/7 Min. Scale
26-42 Terminal X42/7 Max. Scale
26-43 Terminal X42/7 Bus Control
26-44 Terminal X42/7 Timeout Preset
26-5* Analog Out X42/9
26-50 Terminal X42/9 Output
26-51 Terminal X42/9 Min. Scale
26-52 Terminal X42/9 Max. Scale
26-53 Terminal X42/9 Bus Control
26-54 Terminal X42/9 Timeout Preset
26-6* Analog Out X42/11
26-60 Terminal X42/11 Output
26-61 Terminal X42/11 Min. Scale
26-62 Terminal X42/11 Max. Scale
26-63 Terminal X42/11 Bus Control
26-64 Terminal X42/11 Timeout Preset
Table 4.24
4.1.24 Cascade CTL Option 27-**
Par. Parameter description
No. #
27-0* Control & Status
27-01 Pump Status
27-02 Manual Pump Control
27-03 Current Runtime Hours
27-04 Pump Total Lifetime Hours
27-1* Configuration
®
VLT AQUA Drive Programming Guide
Default value
[1] Voltage
[1] Voltage
[1] Voltage
0.07 V
10 V
0 N/A
100 N/A
0.001 s
[1] Enabled
0.07 V
10 V
0 N/A
100 N/A
0.001 s
[1] Enabled
0.07 V
10 V
0 N/A
100 N/A
0.001 s
[1] Enabled
[0] No operation
0 %
100 %
0 %
0 %
[0] No operation
0 %
100 %
0 %
0 %
[0] No operation
0 %
100 %
0 %
0 %
Default value
[0] Ready
[0] No Operation
0 h
0 h
®
MG20O622 - VLT is a registered Danfoss trademark
4-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion index
- Uint8
- Uint8
4
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
Type
- Uint8
- Uint8
74 Uint32
74 Uint32
4-21
4
