Parameter Description
10-51 Process Data Config Read.
Option:
[1502] kWh Counter
3 3
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1619] KTY sensor temperature
[1620] Motor Angle
[1622] Torque [%]
[1625] Torque [Nm] High
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback [Unit]
[1653] Digi Pot Reference
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
3-72
®
VLT AQUA Drive Programming Guide
10-51 Process Data Config Read.
Function: Option:
[1678]
[1679]
[1684]
[1685]
[1690]
[1691]
[1692]
[1693]
[1694]
[3421]
[3422]
[3423]
[3424]
[3425]
[3426]
[3427]
[3428]
[3429]
[3430]
[3440]
[3441]
[3450]
[3451]
[3452]
[3453]
[3454]
[3455]
[3456]
[3457]
[3458]
[3459]
[3460]
[3461]
[3462]
[3464]
[3465]
[3470]
[3471]
®
MG20O622 - VLT is a registered Danfoss trademark
Analog Out X45/1 [mA]
Analog Out X45/3 [mA]
Comm. Option STW
FC Port CTW 1
Alarm Word
Alarm Word 2
Warning Word
Warning Word 2
Ext. Status Word
PCD 1 Read from MCO
PCD 2 Read from MCO
PCD 3 Read from MCO
PCD 4 Read from MCO
PCD 5 Read from MCO
PCD 6 Read from MCO
PCD 7 Read from MCO
PCD 8 Read from MCO
PCD 9 Read from MCO
PCD 10 Read from MCO
Digital Inputs
Digital Outputs
Actual Position
Commanded Position
Actual Master Position
Slave Index Position
Master Index Position
Curve Position
Track Error
Synchronizing Error
Actual Velocity
Actual Master Velocity
Synchronizing Status
Axis Status
Program Status
MCO 302 Status
MCO 302 Control
MCO Alarm Word 1
MCO Alarm Word 2
Function:
