How to Program

2.2.8 Main Menu Mode

2 2
Start Main Menu mode by pressing [Main Menu]. The
readout shown below appears on the display.
The middle and bottom sections on the display show a list
of parameter groups which can be chosen by toggling [
▼
and [ ] keys.
Figure 2.10
Each parameter has a name and number which remain the
same regardless of the programming mode. In main menu
mode, the parameters are divided into groups. The first
digit of the parameter number (from the left) indicates the
parameter group number.
All parameters can be changed in the Main Menu.
However, depending on the choice of configuration
(1-00 Configuration Mode), some parameters can be
"missing". For example, open-loop hides all the PID
parameters, and other enabled options make more
parameter groups visible.

2.2.9 Parameter Selection

In Main menu mode, the parameters are divided into
groups. Select a parameter group with the navigation keys.
The following parameter groups are accessible:
Group # Parameter group
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** References/Ramps
4-** Limits/Warnings
5-** Digital In/Out
6-** Analog In/Out
7-** Controls
8-** Comm. and Options
9-** Profibus
10-** CAN Ser. Com. Bus
11-** Reserved Com. 1
12-** Reserved Com. 2
2-8
®
VLT AQUA Drive Programming Guide
1107 RPM 3.84 A
Main Menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
MG20O622 - VLT
Group # Parameter group
13-** Smart Logic
14-** Special Functions
15-** Drive Information
16-** Data Readouts
▲
]
17-** Motor Feedb. Option
18-** Data Readouts 2
30-** Special Features
32-** MCO Basic Settings
1 (1)
33-** MCO Adv. Settings
34-** MCO Data Readouts
Table 2.5
After selecting a parameter group, choose a parameter by
means of the navigation keys.
The middle section on the display shows the parameter
number and name as well as the selected parameter value.
Figure 2.11

2.2.10 Changing Data

The procedure for changing data is the same in the Quick
menu and Main Menu mode. Press [OK] to change the
selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.
®
is a registered Danfoss trademark
740RPM 10.64A 1 [1]
Basic Settings 0-0*
0 -01 Language
[0] English
