Parameter Description
[28] Brake, no
warning
[29] Brake ready, no
fault
3 3
[30] Brake fault
(IGBT)
[35] External
Interlock
[40] Out of ref range
[41] Below reference
low
[42] Above reference
high
[45] Bus Ctrl
[46] Bus Ctrl 1 if
timeout
[47] Bus Ctrl 0 if
timeout
[55] Pulse output
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic Rule 0
3-48
®
VLT AQUA Drive Programming Guide
The brake is active and there are no
warnings.
The brake is ready for operation and
there are no faults.
The output is Logic '1' when the brake
IGBT is short-circuited. Use this function
to protect the adjustable frequency drive
if there is a fault on the brake modules.
Use the output/relay to cut out the line
voltage from the adjustable frequency
drive.
External Interlock function has been
activated via one of the digital inputs.
See parameter group 13-1*. If
Comparator 0 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
See parameter group 13-1*. If
Comparator 1 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
See parameter group 13-1*. If
Comparator 2 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
See parameter group 13-1*. If
Comparator 3 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
See parameter group 13-1*. If
Comparator 4 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
See parameter group 13-1*. If
Comparator 5 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
See parameter group 13-4*. If Logic Rule
0 is evaluated as TRUE, the output will
go high. Otherwise, it will be low.
MG20O622 - VLT
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital
Output A
[81] SL Digital
Output B
[82] SL Digital
Output C
[83] SL Digital
Output D
[84] SL Digital
Output E
[85] SL Digital
Output F
[160] No alarm
[161] Running reverse The output is high when the adjustable
®
is a registered Danfoss trademark
See parameter group 13-4*. If Logic Rule
1 is evaluated as TRUE, the output will
go high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule
2 is evaluated as TRUE, the output will
go high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule
3 is evaluated as TRUE, the output will
go high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule
4 is evaluated as TRUE, the output will
go high. Otherwise, it will be low.
See parameter group 13-4*. If Logic Rule
5 is evaluated as TRUE, the output will
go high. Otherwise, it will be low.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [38] Set digital out A high is
executed. The output will go low
whenever the Smart Logic Action [32] Set
digital out A low is executed.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [39] Set digital out B high is
executed. The output will go low
whenever the Smart Logic Action [33] Set
digital out B low is executed.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [40] Set digital out C high is
executed. The output will go low
whenever the Smart Logic Action [34] Set
digital out C low is executed.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [41] Set digital out D high is
executed. The output will go low
whenever the Smart Logic Action [35] Set
digital out D low is executed.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [42] Set digital out E high is
executed. The output will go low
whenever the Smart Logic Action [36] Set
digital out E low is executed.
See 13-52 SL Controller Action. The output
will go high whenever the Smart Logic
Action [43] Set digital out F high is
executed. The output will go low
whenever the Smart Logic Action [37] Set
digital out F low is executed.
Output is high when no alarm is present.
frequency drive is running counter-
