How to Program
Select My Personal Menu to display the chosen personal
2 2
parameters. These parameters are selected in 0-25 My
Personal Menu. Up to 20 different parameters can be
added in this menu.
Select Quick Set-up to go through a limited amount of
parameters to get the motor running almost optimally. The
default setting for the other parameters considers the
desired control functions and the configuration of signal
inputs/outputs (control terminals).
Parameters are selected by using the arrow keys. The
parameters in Table 2.1 are accessible in the Quick Set-up.
Parameter
0-01 Language
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
3-41 Ramp 1 Ramp-up Time
3-42 Ramp 1 Ramp-down Time [sec]
1-29 Automatic Motor
Adaptation (AMA)
Table 2.1 Parameters in Quick Set-up
Select Changes made to get information about:
•
the last 10 changes. Use the [
between the last ten changed parameters.
•
the changes made since default setting.
•
input assignments
Select Loggings to get information about the display line
readouts. The information is shown as graphs.
It is possible to store up to 120 samples in the memory for
later reference.
2-6
®
VLT AQUA Drive Programming Guide
Unit
[kW]
[V]
[Hz]
[A]
[rpm]
[sec]
[1] Enable complete AMA
▲ ▼
] [ ] keys to scroll
®
