Parameter Description
0-20 Display Line 1.1 Small
Option: Function:
[1659] Adjusted Setpoint Displays the actual operating setpoint
after it is modified by flow compen-
sation. See parameter group 22-8*.
[1660] Digital Input Displays the status of the digital
inputs. Signal low = 0; Signal high =
1.
Regarding order, see 16-60 Digital
Input. Bit 0 is at the extreme right.
[1661] Terminal 53 Setting of input terminal 53. Current
Switch Setting = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a
reference or protection value.
[1663] Terminal 54 Setting of input terminal 54. Current
Switch Setting = 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as
reference or protection value.
[1665] Analog Output 42 Actual value at output 42 in mA. Use
[mA] 6-50 Terminal 42 Output to select the
variable to be represented by output
42.
[1666] Digital Output Binary value of all digital outputs.
[bin]
[1667] Pulse Input #29 Actual value of the frequency applied
[Hz] at terminal 29 as a pulse input.
[1668] Pulse Input #33 Actual value of the frequency applied
[Hz] at terminal 33 as a pulse input.
[1669] Pulse Output #27 Actual value of pulses applied to
[Hz] terminal 27 in digital output mode.
[1670] Pulse Output #29 Actual value of pulses applied to
[Hz] terminal 29 in digital output mode.
[1671] Relay Output [bin] View the setting of all relays.
[1672] Counter A View the present value of Counter A.
[1673] Counter B View the present value of Counter B.
[1675] Analog In X30/11 Actual value of the signal on input
X30/11 (General Purpose I/O Card.
Option)
[1676] Analog In X30/12 Actual value of the signal on input
X30/12 (General Purpose I/O Card.
Optional)
[1677] Analog Out X30/8 Actual value at output X30/8 (General
[mA] Purpose I/O Card. Optional) Use
6-60 Terminal X30/8 Output to select
the variable to be shown.
[1680] Fieldbus CTW 1 Control word (CTW) received from
the bus master.
®
VLT AQUA Drive Programming Guide
0-20 Display Line 1.1 Small
Option:
[1682] Fieldbus REF 1
[1684] Comm. Option
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2 One or more status conditions in a
[1696] Maintenance Word The bits reflect the status for the
[1830] Analog Input
[1831] Analog Input
[1832] Analog Input
[1833] Analog Out X42/7
[1834] Analog Out X42/9
[1835] Analog Out
®
MG20O622 - VLT is a registered Danfoss trademark
Function:
Main reference value sent with
control word via the serial communi-
cations network, e.g. from the BMS,
PLC or other master controller.
Extended serial communication bus
Status option status word.
Control word (CTW) received from
the bus master.
Status word (STW) sent to the bus
master.
One or more alarms in a Hex code
(used for serial communications)
One or more alarms in a Hex code
(used for serial communications)
One or more warnings in a Hex code
(used for serial communications)
One or more warnings in a Hex code
(used for serial communications)
One or more status conditions in a
Hex code (used for serial communi-
cations)
Hex code (used for serial communi-
cations)
preventive maintenance events
programmed in parameter group
23-1*
Shows the value of the signal applied
X42/1 to terminal X42/1 on the Analog I/O
card.
Shows the value of the signal applied
X42/3 to terminal X42/3 on the Analog I/O
card.
Shows the value of the signal applied
X42/5 to terminal X42/5 on the Analog I/O
card.
Shows the value of the signal applied
[V] to terminal X42/7 on the Analog I/O
card.
Shows the value of the signal applied
[V] to terminal X42/9 on the Analog I/O
card.
Shows the value of the signal applied
X42/11 [V] to terminal X42/11 on the Analog I/O
card.
