raSPARC User's Manual
•
Store buffer requests. The store buffer priority is made higher than the load
buffer priority when the store buffer reaches five entries; it remains higher
until the number of entries drops to two.
•
The request for the first 16 bytes of data from the I-Cache/Prefetch Unit. After
the first clock of an I-Cache request, its priority becomes higher than load and
store buffer requests.
The UDB contains:
•
A read buffer that holds a model-dependent number of 64-byte lines coming
from main memory; these satisfy E-Cache read misses or noncacheable reads.
Table 7-3 shows the supported buffer depth for each UltraSPARC model.
Table 7-4 Supported Read Buffer Depth
# of Entries
•
A model-dependent number of 64-byte buffers to hold writebacks, block
stores, and outgoing interrupt vectors. The writeback buffer(s) are in the
coherence domain; consequently, it can be used to satisfy copyback requests
from the system. Table 7-5 shows the number of Writeback buffer entries for
each UltraSPARC model. Note: Models that support more than one Writeback
buffer entry can be restricted to using only one entry.
Table 7-5 Supported Number of Writeback Buffer Entries
# of Entries
•
Eight 16-byte noncacheable store buffers.
•
A 24-byte buffer to hold an incoming Interrupt Vector. (Each UDB chip
contains a 24-byte interrupt vector buffer, but only one buffer is used.)
3.2 UltraSPARC E-Cache and UDB Transactions
This section describes transactions occurring between UltraSPARC, the E-Cache,
and the UDB. Interconnect transactions are described in a later section. Transi-
tions in the timing diagrams show what is seen at the pins of UltraSPARC.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Cache line states are defined in Section 7.6, "Cache Coherence Protocol," on page
UltraSPARC-I UltraSPARC-II
1 3
UltraSPARC-I UltraSPARC-II
1 2
