FMUL8ULx16 Operation
.5.4.6 FMULD8SUx16
FMULD8SUx16 multiplies the upper 8 bits of each 16-bit signed value in rs1 by
the corresponding signed 16-bit fixed point signed integer in rs2. The 24-bit prod-
uct is shifted left by 8-bits to make up a 32-bit result. The result is stored in the
corresponding 32-bit of the destination rd register. The operation is illustrated in
Figure 13-13.
rs1
rs2
6
3
rd
