FV: Fault Valid. Set when the MMU detects a fault; it is cleared only on an
explicit ASI write of 0 to the SFSR register. When FV is not set, the values
of the remaining fields in the SFSR and SFAR are undefined.
The SFSR and the Tag Access registers both maintain state concerning a previous
translation causing an exception. The update policy for the SFSR and the Tag Ac-
cess registers is shown in Table 6-4 on page 51.
Note: A
fast_{instruction
SFAR to be written. In this case the D-SFAR information can be obtained from the
D Tag Access register.
9.5 I-/D-MMU Synchronous Fault Address Registers (SFAR)
9.5.1 I-MMU Fault Address
There is no I-MMU Synchronous Fault Address register. Instead, software must
read the TPC register appropriately as discussed here.
For
instruction_access_MMU_miss
not found in the I-MMU TLB.
For
instruction_access_exception
tains the virtual address of the instruction in the privileged page that caused the
exception.
For
instruction_access_exception
TPC in these cases contains only a 44-bit virtual address, which is sign-extended
based on bit VA<43> for read. Therefore, use the following methods to compute
the virtual address that was out of range:
•
For the branch, CALL, and sequential exception case, the TPC contains the
lower 44 bits of the virtual address that is out of range. Because the hardware
sign-extends a read of the TPC register based on VA<43>, the contents of the
TPC register XORed with FFFF F000 0000 0000
of-range virtual address.
•
For the JMPL or RETURN exception case, the TPC contains the virtual address
