Sun StorEdge
3000 Family
™
FRU Installation Guide
Sun Microsystems, Inc.
www.sun.com
Part No. 816-7326-17
May 2004, Revision A
Submit comments about this document at:
http://www.sun.com/hwdocs/feedback

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StorEdge 3000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems StorEdge 3000 Series

Summary of Contents for Sun Microsystems StorEdge 3000 Series

  • Page 1 Sun StorEdge 3000 Family ™ FRU Installation Guide Sun Microsystems, Inc. www.sun.com Part No. 816-7326-17 May 2004, Revision A Submit comments about this document at: http://www.sun.com/hwdocs/feedback...
  • Page 2 Copyright © 2003-2004 Dot Hill Systems Corporation, 6305 El Camino Real, Carlsbad, California 92009, USA. All rights reserved. Sun Microsystems, Inc. and Dot Hill Systems Corporation may have intellectual property rights relating to technology embodied in this product or document. In particular, and without limitation, these intellectual property rights may include one or more of the U.S. patents listed at http://www.sun.com/patents and one or more additional patents or pending patent applications in the U.S.

  • Page 3: Table Of Contents

    Contents Sun StorEdge 3000 Family FRUs 1–1 Available FRUs 1–2 Static Electricity Precautions 1–5 Powering Off the Array 1–5 Disk Drive, Air Management Sled, and Tabletop Cover FRUs 2–1 Replacing a Disk Drive 2–2 2.1.1 Identifying the Defective Disk Drive 2–3 2.1.2 Removing a Defective Disk Drive 2–4 2.1.3...
  • Page 4 2.3.2 Converting a Tabletop Array to a Rack-Ready Array 2–14 Power and Fan Module FRUs 3–1 Replacing Power Supply/Fan Modules for 2U Arrays 3–2 3.1.1 Removing an AC Power Supply/Fan Module 3–2 3.1.2 Installing an AC Power Supply/Fan Module 3–3 3.1.3 Replacing a DC Power Supply/Fan Module 3–3 3.1.3.1...
  • Page 5 FC Module FRUs 5–1 Replacing an I/O Controller Module 5–2 5.1.1 Saving the Configuration Settings to NVRAM 5–2 5.1.2 Removing an I/O Controller Module 5–3 5.1.3 Installing an I/O Controller Module 5–6 5.1.4 Monitoring the Automatic Firmware Update with a Recently Installed Controller FRU 5–7 5.1.5 SES Firmware Update Sometimes Required with I/O Controller...
  • Page 6 6.2.3 Installing a SCSI I/O Module 6–7 Replacing the SCSI Terminator Module 6–8 6.3.1 Removing the SCSI Terminator Module 6–8 6.3.2 Installing a Terminator Module 6–9 Replacing the EMU Module 6–10 6.4.1 Removing an EMU Module 6–10 6.4.2 Installing an EMU Module 6–11 Installing a RAID/Expansion Chassis FRU 6–11 Special JBOD Usage With External Terminators 6–14...

  • Page 7: Sun Storedge 3000 Family Frus

    C H A P T E R Sun StorEdge 3000 Family FRUs This document provides instructions for removing and installing field-replaceable ™ units (FRUs) in Sun StorEdge 3120 SCSI arrays, Sun StorEdge 3310 SCSI arrays, and Sun StorEdge 3510 FC arrays, and Sun StorEdge 3511 FC arrays with SATA. Note –...

  • Page 8: Available Frus

    Available FRUs Most FRUs are hot-swappable except a few modules which are hot-serviceable. Hot- serviceable means that the module can be replaced while the RAID product and hosts are powered up but the connected hosts must be inactive. Caution – Please follow the FRU procedures carefully to ensure successful FRU replacement.
  • Page 9 List of Available FRUs for the Sun StorEdge 3310 SCSI Array TABLE 1-2 FRU Model Number Description F370-5394-xx Event monitoring unit F370-5396-xx I/O module, LVD, expansion unit or JBOD F370-5397-xx I/O module, LVD, RAID F370-5403-xx Controller module, 512 memory, battery, 2U LVD F370-5399-xx Terminator module F540-5522-xx...
  • Page 10 List of Available FRUs for the Sun StorEdge 3510 FC Array TABLE 1-3 FRU Model Number Description F370-5535-xx Box, 2U, FC, Chassis + Backplane (RAID/JBOD) F370-5545-xx Battery, FC, 2U F370-5540-xx Cable, FC, 1.5 FT, expansion F370-5537-xx I/O w/SES and RAID Controller FC, 1GB memory, battery, 2U F370-5538-xx I/O w/SES, JBOD FC, 2U F370-5398-xx...

  • Page 11: Static Electricity Precautions

    Static Electricity Precautions Perform these steps to prevent damaging the FRUs: Remove plastic, vinyl, and foam from the work area. Before handling a FRU, discharge any static electricity by touching a ground surface and wear an antistatic wrist strip. Do not remove a FRU from its antistatic protective bag until you are ready to install it.
  • Page 12 3. Power off both power supply/fan modules. Sun StorEdge 3000 Family FRU Installation Guide • May 2004...

  • Page 13: Disk Drive, Air Management Sled, And Tabletop Cover Frus

    C H A P T E R Disk Drive, Air Management Sled, and Tabletop Cover FRUs This chapter provides instructions for removing and installing a disk drive, air management sled, and tabletop cover FRUs, and covers the following topics: “Replacing a Disk Drive” on page 2-2 “Identifying the Defective Disk Drive”...

  • Page 14: Replacing A Disk Drive

    Replacing a Disk Drive To replace a disk drive, you first remove the defective disk drive and then install a replacement drive. The drive module is hot-swappable. It is replaced while the RAID product is powered on. Chassis notch Thumbscrew Handle pin Drive handle The Front View of a Drive Module Pulled Out of the Chassis...

  • Page 15: Identifying The Defective Disk Drive

    2.1.1 Identifying the Defective Disk Drive Before replacing a disk drive, perform the following steps to ensure that you have identified the correct defective disk for removal. Caution – To prevent any possibility of data loss, back up the data prior to removing disk drives.

  • Page 16: Removing A Defective Disk Drive

    a. On the Main Menu, choose “view and edit scsi Drives” and press Return. b. Select the drive you want to identify and press Return. c. Choose the “Identifying scsi drive” function. d. Choose “flash all But selected drive” to flash the activity LEDs of all of the drives in the drive channel except the selected drive, and press Return.

  • Page 17: Installing A New Disk Drive

    Caution – Do not remove a defective module unless you have a replacement FRU module to immediately replace the defective module. If you remove a module and do not replace it, you alter the air flow inside the chassis and could overheat the chassis as a result.

  • Page 18: Scanning The New Drive And Related Procedures

    Caution – Be sure to install a disk drive that is appropriate for your array. Sun StorEdge 3510 FC array disk drives cannot be used in a Sun StorEdge 3511 FC array. Similarly, a Sun StorEdge 3511 disk drive cannot be used in a Sun StorEdge 3510 FC array.

  • Page 19: Checking And Performing The Correct Powerup Sequence

    b. Choose “Scan scsi drive” and press Return. Select the Channel number, then the ID number of the replaced disk drive, and confirm Yes when prompted. c. Verify that the message “Scanned SCSI drive successfully” is displayed. 3. From the Main Menu, choose “view and edit Logical drives” and use the following table to continue.

  • Page 20: Assigning A Disk Drive As A Spare

    Host server(s) last (if they had been powered down for maintenance purposes) 2. Check the logical drive status in the “view and edit Logical drive” window. If the status is GOOD, no further steps are needed. 3. If the logical drive status is FATAL FAIL, two or more disk drives may have failed, data may be lost, and you may have to create a new logical drive.

  • Page 21: If The Logical Drive Status Is Rebuilding

    4. Disable Periodic Drive Check Time: From the Main Menu, choose “view and edit Configuration parameters,” then choose “Drive-side SCSI Parameters.” Set the “Periodic Drive Check Time” option to Disabled, then confirm Yes. This procedure is now complete. 2.1.4.4 If the Logical Drive Status is REBUILDING The rebuilding process refers to the rebuilding of the logical drive in which the data from a defective disk drive is restored to a global spare.
  • Page 22 Note – These features are Disabled by default. These features requires system resources and can impact performance. Periodic Auto-Detect Failure Drive Swap Check Time This menu option periodically polls the unit to detect the replacement of a bad drive. If no spare drive is present in the array, the logical drive begins an automatic rebuild of a degraded RAID set when the firmware detects replacement of the bad drive.

  • Page 23: Installing An Air Management Sled

    Installing an Air Management Sled An air management sled looks identical to the disk drive module; however, it is an empty box and is used to maintain optimum airflow in a chassis. If you remove a disk drive and do not replace it, you can insert an air management sled to maintain the optimum airflow inside the chassis.

  • Page 24: Converting A Rack-Ready Array To A Tabletop Array

    2.3.1 Converting a Rack-Ready Array to a Tabletop Array Perform the following steps to convert a rackmounted or rack-ready array to a tabletop array. 1. If attached, unlock the front bezel cover with the provided key, and pull it forward and downward. Then press the right bezel arm (hinge) towards the left side to release it from the chassis hole.
  • Page 25 Front of tabletop cover Back of RAID product Front of RAID product Sliding the Chassis Into the Tabletop Cover FIGURE 2-4 Screws to attach the cover to the chassis ears Chassis ear LEDs Attaching the Chassis Ears to the Tabletop Cover FIGURE 2-5 9.

  • Page 26: Converting A Tabletop Array To A Rack-Ready Array

    a. Align the top and bottom edges of each cap with the top and bottom edges of each chassis ear. b. While holding the side of the chassis with one hand, push the cap onto the ear with the other hand. Be sure to place the cap with LED labels on the right ear. Caution –...

  • Page 27: Power And Fan Module Frus

    C H A P T E R Power and Fan Module FRUs Topics covered in this chapter are: “Replacing Power Supply/Fan Modules for 2U Arrays” on page 3-2 “Replacing Power Supply/Fan Modules for 1U Arrays” on page 3-5 The following power specifications apply to the power supply and fan modules: Power Specifications TABLE 3-1 AC power:...

  • Page 28: Replacing Power Supply/Fan Modules For 2U Arrays

    Replacing Power Supply/Fan Modules for 2U Arrays Caution – To avoid damage to equipment, do not remove a power supply/fan module without a working replacement. 3.1.1 Removing an AC Power Supply/Fan Module Be sure to follow “Static Electricity Precautions” on page 1-5.

  • Page 29: Installing An Ac Power Supply/Fan Module

    3.1.2 Installing an AC Power Supply/Fan Module 1. Slide the new module into the fan and power supply slot. 2. Push the latch back so that the power supply is fully inserted into the chassis. 3. Turn the thumbscrew at the top of the power supply latch clockwise until it is finger-tight, to secure the module.
  • Page 30 3. Turn the thumbscrew at the top of the power supply latch clockwise until it is finger-tight to secure the module. Note – To ensure that a thumbscrew is finger-tight, tighten it with a screwdriver and then loosen the thumbscrew counterclockwise a quarter-turn. 4.

  • Page 31: Replacing Power Supply/Fan Modules For 1U Arrays

    Replacing Power Supply/Fan Modules for 1U Arrays 3.2.1 Replacing an AC Power Supply/Fan Module Caution – To avoid damage to equipment, do not remove a power supply/fan module without a working replacement. 3.2.1.1 Removing an AC Power Supply/Fan Module 1. Be sure to follow “Static Electricity Precautions”...

  • Page 32: Installing An Ac Power Supply/Fan Module

    3.2.1.2 Installing an AC Power Supply/Fan Module 1. Slide the new module into the fan and power supply slot. 2. Push the latch back so that the power supply is fully inserted into the chassis. 3. Turn the thumbscrew at the top of the power supply latch clockwise until it is finger-tight, to secure the module.

  • Page 33: Installing An Dc Power Supply/Fan Module

    4. Pull the latch forward about 90 degrees to disconnect the power supply/fan module from the midplane. 5. Pull the power supply/fan module out of the chassis. 3.2.2.2 Installing an DC Power Supply/Fan Module 1. Slide the new module into the fan and power supply slot. 2.
  • Page 34 Sun StorEdge 3000 Family FRU Installation Guide • May 2004...

  • Page 35: Battery Frus

    C H A P T E R Battery FRUs This chapter provides instructions for removing and installing batteries and battery modules. The FC arrays have an independent battery module located above each I/O module. The SCSI arrays contain a battery on each controller module. The battery dating information is the same for all batteries.

  • Page 36: Battery Operation

    Battery Operation Your lithium ion battery should be changed every two years if the unit is continuously operated at 25 degrees C. If the unit is continuously operated at 35 degrees C or higher, it should be changed every year. The shelf life of your battery is three years.

  • Page 37: Battery Dating On The Battery Labels

    Battery Status Indicators TABLE 4-1 Battery Display Description ----- Discharged; the battery is automatically recharged when it reaches this state. +---- Adequately charged to maintain cache memory for 72 hours or more in case of power loss. Automatic recharging occurs when the battery status drops below this level.
  • Page 38 Date code of manufacture (yyww=year+week) Battery 0000044–02403000001 Serial number 3705555-04 Part number Battery Label Example for the Sun StorEdge 3310 SCSI Array FIGURE 4-1 Date code of manufacture (yyww=year+week) Battery 66-00000057/50 Part number 0000043-0303000274 Serial number Battery Label Example for the Sun StorEdge 3510 FC Array FIGURE 4-2 , the number below the bottom bar code is the part number (for FIGURE 4-1...

  • Page 39: Replacing A Battery

    Replacing a Battery This section explains how to remove an existing battery and install a new battery. The following procedures are guidelines for replacing batteries in SCSI and FC arrays. 4.4.1 Replacing a SCSI Battery To replace a SCSI array battery, perform the following steps (refer to FIGURE 4-3 through FIGURE 4-7...
  • Page 40 Battery Connector The Battery and Connector in a SCSI Array FIGURE 4-3 The Battery Connector Unplugged in a SCSI Array FIGURE 4-4 Sun StorEdge 3000 Family FRU Installation Guide • May 2004...
  • Page 41 The Underside of the Battery Module With Screws Being Removed FIGURE 4-5 The Top Side of the Controller Module With the Battery Being Lifted Out and FIGURE 4-6 the Connector Unplugged Chapter 4 Battery FRUs...

  • Page 42: Replacing An Fc Battery

    The Top and Side View of the Controller Module With the Battery Being FIGURE 4-7 Inserted 4.4.2 Replacing an FC Battery To replace a FC array battery, perform the following steps. 1. Turn the thumbscrews on the left and right sides of a battery module for the FC array counterclockwise until the thumbscrews are disengaged from the chassis.
  • Page 43 Battery Module Removed From the Chassis FIGURE 4-8 Battery Connector Disconnected From the Battery Module FIGURE 4-9 4. Remove the battery screws on the underside of the module to release the battery from the battery module, similar to the screw removal shown in FIGURE 4-5 5.

  • Page 44: Fc Battery Status And In-Service Date Procedures

    FC Battery Status and In-Service Date Procedures The CLI and SSCS programs offer the following features for FC battery modules: Setting the In-Service Date Monitoring the FC battery status 4.5.1 Viewing Status and Setting the In-Service Date with the CLI This command sets the in-service date for battery FRU replacements and displays the status of the battery modules.

  • Page 45: Viewing Status And Setting The In-Service Date With Sscs

    The following example shows one good battery one and one battery that is set to expire within the next week: sccli> show battery-status Upper Battery Type: 1 Upper Battery Manufacturing Date: Sat Jan 04 00:00:00 2003 Upper Battery Placed In Service: Thu Jan 22 10:59:58 2004 Upper Battery Expiration Date: Tue Jan 03 06:00:00 2006...
  • Page 46 To view the battery status, choose View → View Enclosure or double-click the enclosure. The View Enclosure window is displayed, showing the battery status in the Summary box. To view battery information, including type, status, manufacture date, in-service date, and expiration date, click Battery. The Battery Information window is displayed.

  • Page 47: Verifying The In-Service Date When Replacing A Battery In Sscs

    4.5.3 Verifying the In-Service Date When Replacing a Battery in SSCS When Sun StorEdge Configuration Service detects a battery FRU, the enclosure icon displays a degraded (yellow) status symbol as shown in the following example. 1. Double-click the enclosure icon. Sun StorEdge Configuration Service calculates the battery expiration date using the in-service date (date that the battery is put into service), which is based on the host clock.
  • Page 48 2. If the host clock is correct, click Yes. The following confirmation message is displayed. Click OK. Sun StorEdge Configuration Service sets the in-service date and displays the date in the In-Service Date field in the Battery Information window. 3. If the host clock is incorrect, click No and reset the clock so that Sun StorEdge Configuration Service can prompt you to verify it again and set the in-service date.

  • Page 49: Fc Module Frus

    C H A P T E R FC Module FRUs This chapter provides instructions for removing and installing field-replaceable units (FRUs) in Sun StorEdge 3510 and 3511 FC arrays. Topics covered in this chapter are: “Replacing an I/O Controller Module” on page 5-2 “Saving the Configuration Settings to NVRAM”...

  • Page 50: Replacing An I/O Controller Module

    Replacing an I/O Controller Module Be sure to follow the “Static Electricity Precautions” on page 1-5. The I/O controller modules are hot-serviceable. Hot-serviceable means that the module can be replaced while the array and hosts are powered on but the connected hosts must be inactive. Caution –...

  • Page 51: Removing An I/O Controller Module

    5.1.2 Removing an I/O Controller Module 1. Keep the array powered on, and make sure that the connected hosts are inactive. Note – Most users who have multiple host connections between the two controllers use multi-pathing software to manage them. If multi-pathing software and connectivity are not possible, one alternative is to power off the array and discontinue all host I/O until the replacement is completed and the array is powered on.
  • Page 52 Servers and consoles FC devices Management console FC expansion units/FC arrays FC device connections application/data servers and consoles Hardware Connections on the Back of a Dual-Controller Sun StorEdge 3510 FC Array FIGURE 5-1 Sun StorEdge 3000 Family FRU Installation Guide • May 2004...
  • Page 53 Servers and consoles FC devices Management console FC expansion units/FC arrays FC device connections application/data servers and consoles Hardware Connections on the Back of a Dual-Controller Sun StorEdge 3511 FC Array FIGURE 5-2 Management is in-band through fibre host connections and out-of-band through the serial port and Ethernet port on the back of each controller.

  • Page 54: Installing An I/O Controller Module

    5.1.3 Installing an I/O Controller Module 1. Keep the array powered on. Gently slide the I/O controller module into the unit until it clicks and is seated in the backplane. Caution – Be sure that the module is properly inserted in the guide rails of the array and that you keep the power on.

  • Page 55: Monitoring The Automatic Firmware Update With A Recently Installed Controller Fru

    Note – The beep code that identifies an SES or PLD firmware mismatch is the repeating Morse code letter “R,” dot dash dot. To solve this mismatch, refer to “SES Firmware Update Sometimes Required with I/O Controller Module Replacements” on page 5-8.

  • Page 56: Ses Firmware Update Sometimes Required With I/O Controller Module Replacements

    Scanning Status: Install Controller FRU. The installed controller is performing self-test and scanning disk channels. This is also the state where the controller will update the firmware on the newly installed controller if not identical to the running firmware version. The controllers can remain in this state for up to 10 minutes depending upon system activity.
  • Page 57 SunSolve has extensive search capabilities that can help you find the appropriate patch, as well as regular patch reports and alerts to let you know when firmware upgrades and related patches become available. In addition, SunSolve provides reports about bugs that have been fixed in patch updates. Each patch includes an associated Readme text file that provides detailed instructions about how to download and install that patch.

  • Page 58: Converting A Dual-Controller Array To A Single Controller Array

    5.1.6 Converting a Dual-Controller Array to a Single Controller Array If you convert a dual-controller array into a single-controller array, the Sun StorEdge Configuration Service software does not automatically recognize the change and reports that the SES and battery board from the removed controller are failed or not present.

  • Page 59: Replacing I/O Expansion Modules

    3. To implement the revised configuration settings from step 1 or step 2, choose “system Functions” from the Main Menu, choose “Reset controller” and press Return. Then choose Yes to confirm. Replacing I/O Expansion Modules Be sure to follow “Static Electricity Precautions” on page 1-5.

  • Page 60: Installing Small Form-Factor Pluggable Transceivers

    Note – To ensure that a thumbscrew is finger-tight, tighten it with a screwdriver and then loosen the thumbscrew counterclockwise a quarter-turn. When you power on your array, if you hear an audible alarm and see a blinking amber Event light on the front of your array, the SES firmware or its associated PLD code in the new controller has a version that is different from the code in the other I/O controller in your array.
  • Page 61 H/D/RCC SFP ports Eight SFP Ports on a Sun StorEdge 3511 FC Array I/O Controller Module FIGURE 5-4 Each Sun StorEdge 3510 FC I/O expansion module has two SFP ports. Sun StorEdge 3511 I/O expansion modules have four SFP ports. On both Sun StorEdge 3510 and 3511 I/O expansion modules, these ports are labeled Loop A or Loop B.

  • Page 62: Installing A Raid/Expansion Chassis Fru

    Note – To remove an SFP, make sure that no cable is connected to it and then slide it out from the port. Installing a RAID/Expansion Chassis The chassis (box) FRU for the Sun StorEdge 3510 and 3511 FC arrays includes a chassis, its drive midplane, and its backplane.
  • Page 63 b. Write down the Controller Unique Identifier (hex) - value. 3. If the defective array is a RAID array, stop all I/O activity and shut down the RAID controller: a. From the Main Menu, choose “system Functions” and press Return. b.
  • Page 64 b. Reset the RAID Controllers: From the Main Menu, choose “system Functions,” then “Reset controller.” Confirm Yes when prompted. c. This procedure is now complete. Proceed with Step 19. If this array is NOT being used by clustered hosts, perform these steps: a.

  • Page 65: Converting An Fc Jbod Into An Fc Raid Array

    Converting an FC JBOD into an FC RAID Array You can convert an FC JBOD (or expansion unit) into a single- or dual-controller FC RAID array by performing the following procedure. Components required for this conversion are: An FC JBOD An FC I/O controller module (two modules for a dual-controller array) Additional SFPs as needed A serial null modem cable for initial configuration of the RAID array...
  • Page 66 3. To convert the JBOD to a RAID array, power off the JBOD. 4. Remove all cables connected to the JBOD I/O expansion module(s) which will be replaced by I/O controller module(s). 5. Remove the top I/O expansion module with the following steps. a.
  • Page 67 In a dual-controller Sun StorEdge 3511 FC array ( ), the recommended FIGURE 5-8 configuration is SFPs plugged into the following ports: The upper I/O controller module with SFPs in the left-most FC0 port, the FC2, and FC4 ports. The lower I/O controller module with SFPs in the left-most FC1 port, the FC3, and FC5 ports.
  • Page 68 H/D/RCC Host port FC0 Host port FC5 Host port FC1 Host port FC4 Sun StorEdge 3511 FC Array Single-Controller SFP Placement FIGURE 5-10 7. Insert additional SFPs into the new I/O controller module as needed. 8. Install an I/O controller module into the top slot with the following steps. a.
  • Page 69 # tip -38400 /dev/ttyn where n is the COM port identifier. For instance, if you have connected the array to the COM port identified as ttyb, use this command: # tip -38400 /dev/ttyb Refresh your screen by holding down the Control key on your keyboard and pressing the letter L key on your keyboard.
  • Page 70 c. Type in the value 0 (to automatically read the chassis serial number from the midplane) and press Return. The value 0 is immediately replaced with the hex value of the chassis serial number. d. To implement the revised parameter value, choose “system Functions” on the Main Menu, choose “Reset Controller”...
  • Page 71 c. Click View → View Server. d. Double-click on the server which had the JBOD connected to it. Click the Probe button. The JBOD connections are removed now. e. Click Array Administration → Controller Assignment. The Assign Server to Manage a RAID Controller window is displayed. f.
  • Page 72 Firmware version To check that you have the latest firmware, go to: http://sunsolve.sun.com and select Patch Portal. Browse in the Sun Alert Patch Report, or check the release notes for your array for firmware patch information. b. Check the number on each I/O controller module faceplate where there is a four-digit number such as 03/50 or 04/50.
  • Page 73 Note – Each operating system has additional procedures or requirements for seeing a new device. For instructions related to each operating system, refer to the appropriate appendix in the Sun StorEdge 3510 and 3511 FC Array Installation, Operation, and Service Manual. Note –...
  • Page 74 5-26 Sun StorEdge 3000 Family FRU Installation Guide • May 2004...

  • Page 75: Scsi Module Frus

    C H A P T E R SCSI Module FRUs This chapter provides instructions for removing and installing field-replaceable units (FRUs) in Sun StorEdge 3310 SCSI arrays. Topics covered in this chapter are: “Replacing a SCSI Controller Module” on page 6-2 “Saving the Configuration Settings to NVRAM”...

  • Page 76: Replacing A Scsi Controller Module

    Replacing a SCSI Controller Module Be sure to follow the “Static Electricity Precautions” on page 1-5. The controller modules are hot-swappable. 6.1.1 Saving the Configuration Settings to NVRAM Before replacing a controller module, save the configuration settings to NVRAM. If power is removed before you replace a controller module, the settings can be restored from NVRAM.

  • Page 77: Installing A Scsi Controller Module

    6.1.3 Installing a SCSI Controller Module 1. Keep the array powered on. Gently slide the controller module into the unit until it clicks and is seated in the backplane. Caution – Be sure that the module is properly inserted into the guide rails of the array.

  • Page 78: Monitoring The Automatic Firmware Update With A Recently Installed Controller Fru

    Caution – Follow the upgrade instructions in the patch README file with great care, to download and install firmware correctly. If the wrong firmware is installed, or the firmware is installed on the wrong device, your controller may be rendered inoperable.

  • Page 79: Replacing A Single-Controller Array Or Powered Off Array

    Scanning Status: Install Controller FRU. The installed controller is performing self-test and scanning disk channels. This is also the state where the controller will update the firmware on the newly installed controller if not identical to the running firmware revision. The controllers can remain in this state for up to 10 minutes depending upon system activity.

  • Page 80: Replacing Scsi I/O Modules

    2. Set the parameter called the “Controller Unique Identifier” to the correct value: a. From the firmware Main Menu, select “view and edit Configuration parameters,” select “Controller Parameters,” and press Return. b. From the Controller Parameters menu, choose “Controller Unique Identifier <hex>”...

  • Page 81: Removing The Scsi I/O Module

    2. Attach the adhesive side of the gasket to the top inside edge of the I/O module faceplate. This will look identical to the gasket already on the bottom inside edge of the I/O module faceplate. 6.2.2 Removing the SCSI I/O Module Caution –...

  • Page 82: Replacing The Scsi Terminator Module

    Note – An improperly seated I/O module commonly causes SCSI channel errors. 4. Reinstall all SCSI cables in their original positions. 5. Power on both power supply modules. Replacing the SCSI Terminator Module Be sure to follow “Static Electricity Precautions” on page 1-5.

  • Page 83: Installing A Terminator Module

    The Terminator Module Partially Pulled Out of the Chassis FIGURE 6-1 6.3.2 Installing a Terminator Module 1. Keep the array powered off. 2. Slide the terminator module into the chassis until it is seated in the backplane. Caution – Be sure that the terminator module is properly inserted into the guide rails of the array.

  • Page 84: Replacing The Emu Module

    5. Power on both power supply modules of the array. Replacing the EMU Module Be sure to follow “Static Electricity Precautions” on page 1-5. The EMU module is hot-swappable and can be replaced with the array powered on. The EMU Module Partially Pulled out of the Chassis FIGURE 6-2 6.4.1 Removing an EMU Module...

  • Page 85: Installing An Emu Module

    6.4.2 Installing an EMU Module 1. With the power on, slide the new EMU module into the chassis until it is firmly seated in the backplane and the module’s front panel is flush with the chassis. Caution – Be sure that the EMU module is properly inserted into the guide rails of the array.
  • Page 86 To configure the array, refer to the installation manual for your array, located on your Sun StorEdge 3000 Family Documentation CD. To replace the chassis frame of an existing RAID array or expansion unit, perform the following steps. 1. Connect to the firmware application via the serial interface (tip for Solaris/Linux) or via telnet.
  • Page 87 a. Connect to the array console menu interface via the serial interface (tip for Solaris/Linux) or via telnet. b. From the Main Menu, choose “view and edit Configuration parameters,” then “Controller Parameters.” c. Select “Controller Unique Identifier (hex).” 17. If this array is being used by clustered hosts, or for any other reason its attached hosts require that their Device IDs remaining consistent, perform these steps: a.

  • Page 88: Special Jbod Usage With External Terminators

    The value 0 is immediately replaced with the hex value of the chassis serial number. d. To implement the revised parameter value, choose “system Functions” on the Main Menu, choose “Reset Controller” and press Return. 19. Connect the array to hosts according to the configuration identified in Step 4 Step 5.

  • Page 89: External Terminators For Special Dual-Bus Jbod Maintenance

    6.6.1 External Terminators for Special Dual-Bus JBOD Maintenance If you have JBOD I/O modules, part number 370-5396-02/50 or higher, use this information. Note – This new I/O module supports both single-initiator and multi-initiator dual- bus configurations. The older I/O module supports only single-initiator dual-bus configurations.

  • Page 90: Older Jbod Dual-Bus Configurations

    Caution – SCSI IDs are based on the cabling of the array when the array is powered up. If you are removing host connections from a dual-host dual-bus multi-initiator configuration, use terminators to preserve the existing SCSI ID assignments (as well as the termination on the bottom SCSI ports).
  • Page 91 Caution – In a cluster configuration, adding a separate host connection that was not originally planned for the array will cause a change in SCSI IDs and therefore loses access to data stored under the original SCSI IDs. To keep other host connections operational while one host connection is temporarily removed, perform the following steps.
  • Page 92 Scenario #1 Disconnect 1 cable from A-IN port: 1. Disconnect Host 1 cable from port A-IN. 2. Unplug cable from port A-OUT and move it to port A-IN. 3. Install a terminator in port A-OUT. Scenario #2 Disconnect 1 cable from B-IN port: 1.

  • Page 93: Installing A Filler Panel On A Scsi Array

    Installing a Filler Panel on a SCSI Array The filler panel FRU is a single metal panel used to cover an empty controller module slot on the rear of a Sun StorEdge 3310 SCSI array. Most often, this occurs when you wish to remove a controller module and change a dual-controller array to a single-controller array.
  • Page 94 6-20 Sun StorEdge 3000 Family FRU Installation Guide • May 2004...

  • Page 95: Sun Storedge 3120 Scsi Array Frus

    C H A P T E R Sun StorEdge 3120 SCSI Array FRUs This chapter provides instructions for removing and installing field-replaceable units (FRUs) which are specific to the Sun StorEdge 3120 SCSI array. FRU components can be replaced by customers or by Sun service representatives. At this time, there is only one FRU procedure which is unique to the Sun StorEdge 3120 SCSI array.

  • Page 96: Note - Be Sure To Follow "Static Electricity Precautions

    Caution – Connected hosts must be inactive during this replacement procedure. Note – Be sure to follow “Static Electricity Precautions” on page 1-5 for all procedures. 1. Power off both power supply modules on the defective array. 2. Ensure all SCSI cables attached to the I/O module are labeled clearly. 3.
