B.3 PCR/PIC Accesses
An example of the operational flow in using the performance instrumentation is
shown in Figure B-3.
set up PCR
sel
[0,1]
[0,1]
PIC[PCR.sel]
accumulate stat
PIC[PCR.sel]
accumulate stat
Figure B-3
B.4 Performance Instrumentation Counter Events
B.4.1 Instruction Execution Rates
Cycle_cnt [PIC0,PIC1]
Accumulated cycles. This is similar to the SPARC-V9 TICK register, except that
cycle counting is controlled by the PCR.UT and PCR.ST fields.
Instr_cnt [PIC0,PIC1]
