6.9.2 I-/D-TSB Tag Target Registers
The I- and D-TSB Tag Target registers are simply bit-shifted versions of the data
stored in the I- and D-Tag Access registers, respectively. Since the I- or D-Tag Ac-
cess register is updated on an I- or D-TLB miss, respectively, the I- and D-Tag Tar-
get registers appear to software to be updated on an I or D TLB miss.
000 Context
63 61 60
Figure 6-3 MMU Tag Target Registers (Two Registers)
I/D Context<12:0>: The context associated with the missing virtual address.
I/D VA<63:22>: The most significant bits of the missing virtual address.
6.9.3 Context Registers
The context registers are shared by the I- and D-MMUs. The Primary Context
Register is defined as follows:
63
Figure 6-4 D-MMU Primary Context Register
PContext: Context identifier for the primary address space.
The Secondary Context register is defined as follows:
63
Figure 6-5 D-MMU Secondary Context Register
SContext: Context identifier for the secondary address space.
The Nucleus Context register is hardwired to zero:
0000000000000000000000000000000000000000000000000000000000000000
63
Figure 6-6 D-MMU Nucleus Context Register
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
—
48 47 42 41
—
—
6. MMU Internal Architecture
VA<63:22>
PContext
13 12
SContext
13 12
Sun Microelectronics
0
0
0
0
57
