ing address by XORing ones into the upper 20 bits. See also Section 6.9.4, "I-/D-
MMU Synchronous Fault Status Registers (SFSR)," on page 58 and Section 6.9.5,
"I-/D-MMU Synchronous Fault Address Registers (SFAR)," on page 60.
When a trap occurs on the delay slot of a taken branch or call whose target is out-
of-range, or the last instruction below the VA hole, UltraSPARC records the fact
that nPC points to an out of range instruction. If the trap handler executes a
DONE or RETRY without saving nPC, the
taken when the instruction at nPC is executed. If nPC is saved and subsequently
restored by the trap handler, the fact that nPC points to an out of range instruc-
tion is lost. To guarantee that all out of range instruction accesses will cause
traps, software should not map addresses within 2
hole as executable.
An out of range address during a data access will result in a
trap if PSTATE.AM is not set. Because the D-MMU SFAR contains only 44 bits,
the trap handler must decode the load or store instruction if the full 64-bit virtual
address is needed. See also Section 6.9.4, "I-/D-MMU Synchronous Fault Status
Registers (SFSR)," on page 58 and Section 6.9.5, "I-/D-MMU Synchronous Fault
Address Registers (SFAR)," on page 60.
14.1.7 TICK Register
UltraSPARC implements a 63-bit TICK counter. For the state of this register at re-
set, see Table 10-1, "Machine State After Reset and in RED_state," on page 172.
Table 14-1
Bits
<63>
<62:0>
Non-privileged Trap enable. If set, an attempt by non-privileged software
NPT:
to read the TICK register causes a
nonprivileged software can read this register with the RDTICK
instruction. This register can only be written by privileged software. A
write attempt by nonprivileged software causes a
counter: 63-bit elapsed CPU clock cycle counter.
Note: TICK.NPT is set and TICK.counter is cleared after both a Power-On-Reset
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
(POR) and an Externally Initiated Reset (XIR).
TICK Register Format
Field
NPT Non-privileged Trap enable
counter Elapsed CPU clock cycle counter
14. Implementation Dependencies
instruction_access_exception
31
bytes of either side of the VA
data_access_exception
Use
trap. If clear,
privileged_action
privileged_action
trap will be
RW
RW
RW
trap.
