Interface Debug - Xilinx LogiCORE IP AXI Product Manual

Table B-1: Ports Used for Transceiver Debug (Cont'd)
Port
PIPE_DEBUG_6/gt_rxcommadet
PIPE_DEBUG_7/gt_rdy
PIPE_DEBUG_8/user_rx_converge
PIPE_DEBUG_9/PIPE_TXELECIDLE

Interface Debug

AXI4-Lite Interfaces
Read from a register that does not have all 0s as a default to verify that the interface is
functional. Output s_axi_arready asserts when the read address is valid and output
s_axi_rvalid asserts when the read data/response is valid. If the interface is
unresponsive ensure that the following conditions are met.
• The axi_ctl_aclk and axi_ctl_aclk_out clock inputs are connected and
toggling.
• The interface is not being held in reset, and axi_aresetn is an active-Low reset.
• Ensure that the main core clocks are toggling and that the enables are also asserted.
• Has a simulation been run? Verify in simulation and/or a Vivado lab tools capture that
the waveform is correct for accessing the AXI4-Lite interface.
AXI Bridge for PCI Express v2.4
PG055 June 4, 2014
Direction Width
Generic debug ports to assist debug. These generic debug
ports bring out internal PIPE Wrapper signals, such as raw
GT signals. DEBUG_0 to DEBUG_9 are intended for per
O
lane signals. The bus width of these generic debug ports
depends on the number of lanes configured in the
wrapper.
Generic debug ports to assist debug. These generic debug
ports bring out internal PIPE Wrapper signals, such as raw
GT signals. DEBUG_0 to DEBUG_9 are intended for per
O
lane signals. The bus width of these generic debug ports
depends on the number of lanes configured in the
wrapper.
Generic debug ports to assist debug. These generic debug
ports bring out internal PIPE Wrapper signals, such as raw
GT signals. DEBUG_0 to DEBUG_9 are intended for per
O
lane signals. The bus width of these generic debug ports
depends on the number of lanes configured in the
wrapper.
Generic debug ports to assist debug. These generic debug
ports bring out internal PIPE Wrapper signals, such as raw
GT signals. DEBUG_0 to DEBUG_9 are intended for per
O
lane signals. The bus width of these generic debug ports
depends on the number of lanes configured in the
wrapper.
www.xilinx.com
Appendix B: Debugging
Description
Send Feedback
104
