Chapter 5: Example Design; Overview; Simulation Design Overview - Xilinx LogiCORE IP AXI Product Manual

Example Design
This chapter contains information about the example design provided in the Vivado®
Design Suite.

Overview

The example simulation design for the Endpoint configuration of the AXI-PCIe block
consists of two discrete parts:
• The Root Port Model, a test bench that generates, consumes, and checks PCI Express
bus traffic.
• An AXI BRAM Controller.

Simulation Design Overview

For the simulation design, transactions are sent from the Root Port Model to the AXI Bridge
for PCI Express core configured as an Endpoint and processed inside the AXI BRAM
controller design.
Figure 5-1 illustrates the simulation design provided with the AXI Bridge for PCI Express
core.
