Implementation Design Overview

For implementation design, the AXI-BRAM controller can be used as a scratch pad memory
to write and read to Block RAM locations.

Example Design Elements

The core wrapper includes:
An example Verilog HDL or VHDL wrapper (instantiates the cores and example design).
A customizable demonstration test bench to simulate the example design.

Example Design Output Structure

Figure 5-2
provides the output structure of the example design.
