3-6-2 Connecting the Black & White Printer
1.) Power OFF/Shutdown the system as described in:
2.) Connect the Black & White printer according to correct connection scheme as described in
Figure 3-6 on page 3-13
NOTE: There are three USB ports (stack) on rear panel. The BW printer may be connected to any of the 3x
USB stack connector.
3.) When all the cables are connected, press the Power ON switch on the Black & White printer.
4.) Power ON/Boot up the LOGIQ™ S7 Expert/Pro system as described in
21. All software drivers are pre-installed for the designated Black & White printer only.
5.) Verify the correct settings in the printer "Properties", see:
Settings" on page
After each installation, the leakage currents have to be measured according to
WARNING WARNING
IEC 60601-1 respectively UL 60601-1.
!! WARNING:
