Table 8-4
NETWORK NAME (SSID)
NETWORK AUTHENTICATION
DATA ENCRYPTION
Specify Yes/No to "The Key is
Provided Automatically"
IEEE 802.1x AUTHENTICATION
8-3-5-2-1-4 Connectivity - Recording the AE Title and Port settings
1.) From the touch panel, select Utility -> Connectivity -> Device.
2.) Select My Computer in the List of Devices, if not already selected.
Figure 8-2 Connectivity - Recording the AE Title and Port settings
3.) Record all settings in
Table 8-5
AE Title
Port Number
MAC Address
4.) Record all settings in
Table 8-6
3 DRAFT (J
Record settings from WLAN screen
PARAMETER
NETWORK KEY
KEY INDEX
INFORMATION
EAP TYPE
Table 8-5.
Record settings for My Computer from Device screen
Parameter
Table 8-6.
Record settings for each device listed in Device table
Name
Chapter 8 - Replacement Procedures
25, 2014)
UNE
VALUE
Value
IP Address
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
8-9
