Product Icons

The following table describes the purpose and location of safety labels and other important information
provided on the equipment.
Table 1-5
LABEL/SYMBOL
Identification and Rating Plate
Device Listing/Certification Labels
xxxx
Type/Class Label
IP Code (IPX 1)
IP Code (IPX 7)
"CAUTION
This unit weighs...
Special care must be used to avoid..."
"DANGER -
Risk of explosion used in..."
3 DRAFT (J
Product Icons
PURPOSE/MEANING
Manufacturer's name and address
Model and serial numbers
Electrical ratings
Laboratory logo or labels denoting conformance with industry
safety standards such as UL or IEC.
Council Directive 93/42/EEC concerning medical devices: The
CE mark affixed to the equipment testifies compliance to the
directive.
Used to indicate the degree of safety or protection.
Indicates the degree of protection provided by the enclosure
per IEC 60529.
IPX 1 - protected against dripping water
IPX 7 - protected against the effects of immersion
Equipment Type BF (man in the box, symbol IEC 60878-5333)
indicates B Type equipment having even more electrical
isolation than standard Type B equipment because it is
intended for intimate patient contact.
To identify a defibrillation-proof type CF (heart in box with
"electrodes", symbol IEC 60878-5336) applied part complying
with IEC 60601-1.
This precaution is intended to prevent injury that may result if
one person attempt to move the unit considerable distances or
on an incline due to the weight of the unit.
The system is not designed for use with flammable anesthetic
gases.
"CAUTION" The equilateral triangle is usually used in
combination with other symbols to advise or warn the user.
ATTENTION - Consult accompanying documents " is
intended to alert the user to refer to the operator manual or
other instructions when complete information cannot be
provided on the label.
