8-3-5-2-1-2 Connectivity - Recording the TCP/IP settings
1.) From the touch panel, select Utility -> Connectivity -> TCP/IP.
2.) Record all settings in
Table 8-3
Computer Name
Enable DHCP
IP-Address
Subnet Mask
Default Gateway
Network Speed
8-3-5-2-1-3 Connectivity — WLAN
1.) Press Utility--> Connectivity--> TCP/IP--> Wireless Network--> Configuration. The Wireless
Network Configuration tool appears. Available Wireless Networks appear.
2.) Select the Properties Tab.
3.) Record all settings in
8-8
3 DRAFT (J
General, Record preset Region, Language and Regional Options. (See the latest revision of
the LOGIQ S7 Expert/Pro Basic User Manual)
Figure 8-1 Connectivity - Recording the TCP/IP settings
Table 8-3.
Record settings from TCP/IP screen
Parameter
ON / OFF
Table 8-4.
Section 8-3 - System Software - Installation/Upgrade Procedure
25, 2014)
UNE
Value
IP Settings
