Section 8-7

Replacement Top Cover

8-7-1 Manpower
1 person, 5 min.
8-7-2 Tools
None required.
8-7-3 Removal Procedure
1.) Top Cover shapes differ for each configuration, but removal/installation procedure are the same.
2.) Slide out Top Cover toward front of the console. No tools required.
3 DRAFT (J
Low Cabinet
Figure 8-18 Cabinet
Figure 8-19 Slide out Top Cover
Chapter 8 - Replacement Procedures
25, 2014)
UNE
Mid Cabinet
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
High Cabinet
