Table 6-2 LCD Montor Adjustment
4
5
Note : 1280 x 1024, 60Hz
6-3-1

Brightness/Contrast

6-3-1-1

Brightness

Adjusting the monitor's contrast and brightness is one of the most important factors for proper image
quality. If these controls are set incorrectly, the Gain, TGC, Dynamic Range and even Acoustic Output
may have to be chaged more often than necessary to compensate.
The proper setup displays a complete gray scale. The lowest level of black should just disappear into
the background and the hightest white should be bright, but not saturated.
1.) Adjust the BRIGHTNESS by pressing the < LEFT or RIGHT> button to decrease/increase value.
3 DRAFT (J
Main Menu
OSD
Exit
Figure 6-2 Brightness Adjust
Chapter 6 - Service Adjustments
25, 2014)
UNE
Sub Menu Range
SBC ON/OFF
English/German/
French/Spanish/
Italian/Swedish/
Language Chinese/Japanese
H-Position 0~100%
V-Position 0~100%
Half Tone 0~100%
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
Setting for
LOGIQ™ S7
Expert/Pro
ON
English
50%
50%
50%
6-3
