Parts List Groups

Part Group Name

Plastics Covers (Front/Sides/Rear)

Nest Box Parts

Mechanical Parts

Optional Peripherals and Accessories

Figure 9-1 Console Views

Mechanical and user accessible parts

Chapter 9 - Renewal Parts

Table Number

Table 9-3 on page 9-4

Table 9-4 on page 9-5

Table 9-5 on page 9-9

Table 9-6 on page 9-13

Table 9-7 on page 9-15

Table 9-8 on page 9-17

Table 9-9 on page 9-18

Table 9-10 on page 9-19

Table 9-11 on page 9-23

Housing Covers

Monitor and its covers

User interface parts

Main board modules

Including front/back end boards

Mechanical Parts and speaker

B/W Printer, Color Printer, Line Printer
