Section 8-23

Replacement of 4D

8-23-1 Manpower
One person, 1 hour.
8-23-2 Tools
Phillips screwdriver.
8-23-3 Removal Procedure
1.) Remove Rear Panel.
2.) Remove Cable Guards.
3.) Remove EMC Plate.
4.) Pull out CPS/CPS2 Assy.
8-23-4 Installation Procedure
Install components in reverse order of removal.
8-23-5 Functional Check
Refer to
8-104
3 DRAFT (J
Section 4-4 for Functional Diag Test List.
