Connecting The Color Printer - GE LOGIQ S7 Expert Service Manual

GE H RAFT
EALTHCARE
D 5460683, R
IRECTION EVISION
3-6-3

Connecting the Color Printer

1.) Power OFF/Shutdown the system as described in:
2.) Connect the Color printer according to correct connection scheme as described in
page
NOTE: There are three USB ports (stack) on rear panel. The Color printer may be connected to any of the 3x
USB stack connector.
3.) When all the cables are connected, press the Power ON switch on the Color printer.
4.) Power ON/Boot up the LOGIQ™ S7 Expert/Pro system as described in
21. All software drivers are pre-installed for the designated Color printer only.
5.) Verify the correct settings in the printer "Properties", see:
Settings" on page
After each installation, the leakage currents have to be measured according to
WARNING WARNING
IEC 60601-1 respectively UL 60601-1.
!! WARNING:
3-14
3 DRAFT (J
3-15.
3-34.
Section 3-6 - Connection of Auxiliary Devices
25, 2014)
UNE
Section 3-7-3 on page
Section 3-8-5 "Adjustment of Printer
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
3-25.
Figure 3-7 on
Section 3-7-2 on page 3-
