3-9-2

External I/O Connectors

1
4
2
Table 3-16
Item Connector Name
1
HDMI Connector
2
NETWORK
3
USB
4
AUDIO
USB 2.0 port
Two hub ports for service and
user
Table 3-17
Item Connector Name
5
USB
3-42
3 DRAFT (J
Figure 3-30 External I/O Connectors - on Rear of System
External I/O Connector - Description
Table Number
Table 5-4 Connector for external Monitor. DVI-D Signal. No audio output.
Table 5-5 DICOM input/output, twisted pair RJ-45 10/100/1000 megabit/s
Table 5-3
Two hub ports
for service and user
Figure 3-31 External I/O Connector
External I/O Connector - Description
Table Number
Table 5-3
Section 3-9 - System Configuration
25, 2014)
UNE
Description
USB-1.1 port. Refer to Section 5-2-4
Connector for External Speaker
5
Description
Connected to GFS via USB HUB. Refer to
details.
LOGIQ™ S7 E
XPERT
S M
ERVICE ANUAL
3
for details.
Section 5-2-4 for
