8-6-4

Installation Procedure

1.) Front cover to be installed in reverse order of removal.
2.) Align the edges and simply push to make sure all three "latches" are engaged.
8-6-5 Functional Check
Visual inspection only.
System Exterior Visual Check
8-38
3 DRAFT (J
Figure 8-17 Installation of latches
Test
Section 8-6 - Replacement Front Cover
25, 2014)
UNE
Refer to
Section 4-3-1
