System Integration Checks

4-3-5-1

OPIO Test

1.) Power ON the system.
2.) Check backlight on AN Keyboard, B Buttons, Freeze Key.
3.) Select UTILITY in touch panel.
4.) Turn encorder knobs as shown in
5.) Verify backlight luminance (intensity) changes when knobs are turned.
3 DRAFT (J
Figure 4-18 OPIO
Fig
Utility
Figure 4-19 OPIO
