GE H
DRAFT
EALTHCARE
D
5460683, R
IRECTION
EVISION
4-3-2-3

OPIO Swivel Lock

1.) Push the swivel button and hold it. (see:
2.) Rotate OPIO (while holding button).
3.) Verify OPIO is free to rotate.
NOTE:
OPIO can rotate approximately 30 degrees to each side.
4.) Let go of Swivel Lock button (disengage).
5.) Verify OPIO does not rotate
Do NOT attempt to apply excessive rotating force to OPIO. OPIO Swivel brake is designed to hold
NOTICE
OPIO in desired position during normal use, and not meant to completely fix the OPIO position.
!! NOTICE:
3
DRAFT (J
Figure 4-7 OPIO Swivel
.
Chapter 4 - Functional Checks
25, 2014)
UNE
Figure
4-7)
LOGIQ™ S7 E
/P
XPERT
RO
S
M
ERVICE
ANUAL
4-8
