Replacement Side Tray & Footrest Cover
8-10-1 Manpower
1 person, 15 min.
8-10-2 Tools
Phillips Driver.
NOTE: "Short" type driver preferable for Foot Rest Cover removal/installation.
8-10-3 Removal Procedure
8-10-3-1 Removal Procedure - Side Tray
Procedures are common for both the Left and Right Side Tray.
1.) Remove 2 screws.
8-46
3 DRAFT (J
Figure 8-28 Side Tray and Foot Rest
Figure 8-29 Side Tray
Section 8-10 - Replacement Side Tray & Footrest Cover
25, 2014)
UNE
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
Side Tray
Foot Rest
