System is equipped with two USB ports in front. These are customer use and Service port connected
to USB controller via USB Hub.
The Rear panel contains following ports.
• USB for peripherals such as printers and footswitch
• HDMI for monitor output (without sound)
• RJ45 for LAN connection
• Mini Jack for sound output
• AC Inlet for power
