Device

To add a new device,
1.) Press Add.
2.) Type the device name in the Name field.
3.) Type the device's IP address in the IP Address field.
Table 3-22
Preset Parameter
Add/Remove
Ping
Properties: Name
Properties: IP Address
Properties: AE Title
Properties: Port Number
Properties: MAC Address
To ping a device,
1.) Select the device.
2.) Press Ping. If the smiley face smiles, then the connection has been confirmed. If the smiley face
frowns, then the connection has not been made. Check the device name and IP address.
3 DRAFT (J
Figure 3-34 Connectivity Device Preset Menu
Device
Press Add to add a new device; press Remove to delete a device.
Press Ping to confirm that a device is connected.
Type the name of the device.
Type the device's IP address.
AE Title of the LOGIQ S7. NOTE: Only available for MyComputer.
IP Port Number Used for DICOM, set by default to 104. NOTE: Only available for MyComputer.
Unique network card address. NOTE: Only available for MyComputer.
