Table 3-5
Step
3.
Remove the option box on front of the system..
4.
Remove the monitor pads from the both sides of the monitor and remove the 4 pads of the box bottom assy..
5.
Carefully remove foam packing material and plastic bag from the ultrasound unit and monitor.
Caution: Two people are needed in the next step due to the weight of the equipment.
3-6
3 DRAFT (J
Unpacking Procedure
Section 3-3 - Receiving and Unpacking the Equipment
25, 2014)
UNE
Task
option box on front of the system
monitor pads
