Section 6-3

LCD Monitor Adjustment

The LOGIQ™ S7 Expert/Pro has a free adjustable LCD monitor in relation to the user interface.
The digital control panel is located at the front of the color monitor. It is NOT recommended to change
the pre-adjusted settings. However, if you are not satisfied with the factory settings, use these
controls to program those you prefer in each resolution.
NOTE: All changed values will only be saved by selecting "Exit" from the OSD.
If not, the adjusted values will be lost after loss of power.
Table 6-2 LCD Montor Adjustment
1
2
3
6-2
3 DRAFT (J
Figure 6-1 Monitor Adjustment buttons
Main Menu
Colortemp/Gamma
Colortemp/Mode
Not Used
Function
Information
Memory Recall
Section 6-3 - LCD Monitor Adjustment
25, 2014)
UNE
Sub Menu Range
Contrast 0~100%
Brighness 0~100%
Select 2.2 or 2.4
9000K/11000K/
13000K/15000K/
USER
Scale Full/5:4/Native
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
Setting for
LOGIQ™ S7
Expert/Pro
100%
80%
2.4
13000K
Full
Factory Default
