GE LOGIQ S7 Expert Service Manual page 107

GE H DRAFT
EALTHCARE
D 5460683, R
IRECTION EVISION
Part
Name Illustration
L8-18i-D
L3-12-D
3Sp-D
S1-4-D
6S-D
S4-10-D
6Tc-RS
3 DRAFT (J
Application
Small Parts, B, CHI, CF, PDI, M, PW, B-Flow, B-Flow
Vascular, Color, Virtual Convex, CrossXBeam,
Neonatal, LOGIQView, ATO/ASO, SRI-HD,
Pediatrics, Advanced 3D, B Steer+
Intraoperative
Abdomen, B, CHI, CF, PDI, M, PW, B-Flow, B-Flow
Vascular Color, Elastography, Virtual Convex,
CrossXBeam, LOGIQView, ATO/ASO,
(No transcranial),
SRI-HD, Advanced3D, Biopsy, B Steer+
Small Parts,
Pediatric, Neonatal
Cardiac, Abdomen, B, CHI, CF, M, MCF, PW, CW, TVI, TVD,
Transcranial Virtual Convex, LOGIQView, ATO/ASO,
Stress Echo, SRI-HD, Advanced 3D,
Biopsy
Cardiac, B, CHI, CF, PDI, M, MCF, PW, CW, TVI,
Transcranial TVD, Virtual Convex, LOGIQView, ATO/
ASO, Stress Echo, SRI-HD,
Advanced3D, Biopsy
Cardiac, B, CHI, CF, PDI, M, MCF, PW, CW, TVI,
Pediatrics, TVD, Virtual Convex, LOGIQView, ATO/
Neonatal ASO, SRI-HD, Advanced3D
Pediatrics, B, CHI, CF, PDI, M, MCF, PW, CW, TVI,
Neonatal, TVD, Virtual Convex, LOGIQView, ATO/
Abdomen ASO, SRI-HD, Advanced 3D
Cardiac B, CHI, CF, PDI, M, MCF, PW, CW, TVI,
TVD, Virtual Convex, ATO/ASO, SRI-HD
(Transesophageal)
Note: Need DLP2RS adapter to connect.
Note: 6Tc-RS probe requires special
handling. Refer to the TEE Probe User
Manual enclosed with 6Tc-RS probe.
Chapter 3 - Setup Instructions
25, 2014)
UNE
Feature
LOGIQ™ S7 E
XPERT
S
ERVICE
Part Probe
Number Type Qty FRU
5410799 Linear
5482856 Linear
GE-3PAX4 Sector
5498609 Sector
5499318 Sector
5394804 Sector
KN100104 TEE
/P
RO
M
ANUAL
1 1
1 1
1 1
1 1
1 1
1 1
1 1
3-45
