Section 5-9

Service Platform

5-9-1

Introduction

The Service Platform will increase service productivity and reduce training and service costs.
5-9-2

Access / Security

The Service Platform has different access and security user levels.
Each user is only granted access to the tools that are authorized for their use.
• Local
5-9-2-1

Local Access

1.) If not already in read mode, FREEZE the image.
2.) Press the UTILITIES key on the control panel and touch SERVICE to invoke setup desktop.
3.) As soon as the GEHC Service Home Page appears, select "Operator" from the pull-down menu,
enter the password uls and then click [Okay]
The Common Service Desktop (CSD) is started and the [Home] page - containing basic System
Information - appears. The navigation bar at the top of the screen allows to select different tools.
For more detailed information and description refer to Section 5-10 on page 5-30.
5-28
3 DRAFT (J
Access: via Utility -
SERVICE
Figure 5-12 Service Login
Section 5-9 - Service Platform
25, 2014)
UNE
button
select: Operator
LOGIQ™ S7 E
S
ERVICE
enter password: uls
/P
XPERT RO
M
ANUAL
