Note on SOM Replacement

SOM retains its memory (date/time/BIOS setting) by receiving 3V from coin battery on GFS Board.
Therefore, when SOM and GFS boards are separated, SOM is likely to loose its date/time setting. In
such case, follow the procedure outlined below to update BIOS information.
8-21-5-1 Configuring BIOS
1.) On bootup, press "DEL" to access BIOS.
2.) When password is prompted, enter "polaris" from AN Keyboard.
3.) After successfully entering BIOS, verify the following parameters.
Table 8-19
TAB
Main
4.) Change date/time parameters as needed, and save the changes.
5.) Reboot the console.
8-96
3 DRAFT (J
Configuring BIOS
top menu
System Time
System Date
Section 8-21 - Replacement of the SOM,HDD and DVR
