Voltage Measurement Points

1.) Remove Front Cover (no tools required)
2.) Remove CSI Cover
3.) On CSI board, there is 12V measurement point
3 DRAFT (J
Figure 7-8 Voltage Measurement Points
Chapter 7 - Diagnostics/Troubleshooting
25, 2014)
UNE
CSI
Cover
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
12V
Measure
Point
