Connectivity Functions

To set up your institution's connectivity, you must login with administrator privileges.
1.) TCPIP: allows you to configure the Internet Protocol.
2.) Device. allows you to set up devices.
3.) Service: allows you to configure a service (for example, DICOM services such as printers, worklist,
and other services such as video print and standard print) from the list of supported services. This
means that the user can configure a device with the DICOM service(s) that particular device
supports.
4.) Dataflow: allows you to adjust the settings of the selected dataflow and associated services.
Selecting a dataflow customizes the ultrasound system to work according to the services
associated with the selected dataflow.
5.) Button: allows you to assign a pre-configured output service (or a set of output services) to the Print
keys on the control panel.
6.) Removable Media: enables formatting (DICOM, database, or blank formatting) and DICOM
verification of removable media.
7.) Miscellaneous: allows you to set up the patient exam menu options, print and store options, and
the order of the columns in the examination list on the Patient menu.
Configure these screens from left to right, starting with the Tcpip tab first.
NOTE: The ultrasound system is pre-configured for many services, with default settings selected. You can
change these services and settings as needed.
You must restart the LOGIQ S7 Expert/Pro (shutdown) after making any changes to connectivity
CAUTION
settings in the Utility menus. This includes any changes on the TCPIP or dataflow setup
!! CAUTION:
screens.
