5-7-4

Air Flow Distribution

NOTE: Clean the Air Filter periodically.
Through the filter grid on the front of the system, air flow into the LOGIQ™ S7 Expert/Pro scanner. By
means of the 1 FAN, air is blown through the nest-box, and the warm air exits the scanner through holes
in the left side panel and rear of the system.
Main Air
Outlet
(Rear)
(Side)
3 DRAFT (J
Figure 5-9 Air Inlet/Outlet at LOGIQ™ S7 Expert/Pro
Chapter 5 - Components and Functions (Theory)
25, 2014)
UNE
LOGIQ™ S7 E /P
XPERT RO
S M
ERVICE ANUAL
Main Air
inlet (Filter grid)
