Table 8-6
8-3-5-2-1-5 Connectivity - Recording Device Destination settings
1.) From the touch panel, select Utility -> Connectivity -> Service.
Figure 8-3 Connectivity - Recording Device Destination settings
2.) Record all settings in
Table 8-7
Destination Device
8-3-5-2-1-6 Connectivity - Recording Dataflow settings
1.) From the touch panel, select Utility -> Connectivity -> Dataflow.
8-10
3 DRAFT (J
Record settings for each device listed in Device table
Name
Table 8-7
Record settings from Service screen
Section 8-3 - System Software - Installation/Upgrade Procedure
25, 2014)
UNE
IP Address
for each Destination Device and Service.
