1. LCD Monitor
2. Touch panel
3. USB port
4. Probe holder
5. A/N Keyboard
6. Control panel swivel
button
7. Control panel up/down
button
1.) Check for no loose or cracked parts on above locations. (see:
3 DRAFT (J
8. Probe holder (Option)
9. DVD Drive
10. BW Printer
11. Color printer or Drawer
12. Foot rest
13. CW pencil probe port
14. Side tray (Option)
Chapter 4 - Functional Checks
25, 2014)
UNE
15. Probe port - 4 active
probe ports
16. Audio speaker
17. Gel warmer or Gel Holder
18. ECG connector
19. Articulating arm
20. External I/O panel
LOGIQ™ S7 E
S
ERVICE
Figure 4-1)
