Table 1-5
LABEL/SYMBOL
1-6
3 DRAFT (J
Product Icons (Continued)
PURPOSE/MEANING
"CAUTION - Dangerous voltage" (the lightning flash with
arrowhead in equilateral triangle) is used to indicate electric
shock hazards.
"Mains OFF" Indicates the power off position of the mains
power switch.
"OFF/Standby" Indicates the power off/standby position of the
power switch.
CAUTION
This Power Switch DOES NOT ISOLATE Mains Supply
"Mains ON" Indicates the power on position of the mains
power switch.
"Protective Earth" Indicates the protective earth (grounding)
terminal.
"Equipotentiality" Indicates the terminal to be used for
connecting equipotential conductors when interconnecting
(grounding) with other equipment.
Waste Electrical and Electronic Equipment (WEEE) Disposal.
This symbol indicates that waste electrical and electronic
equipment must not be disposed as unsorted municipal waste
and must be collected separately. Please contact an
authorized representative of the manufacturer for information
concerning the decommissioning of your equipment.
These symbols indicate that at least one of the six hazardous
substances of the China RoHS Labelling Standard is above
the RoHS limitation.
The number inside the circle is referred to as the
Environmental Friendly Use Period (EFUP). It indicates the
number of years that the product, under normal use, will
remain harmless to health of humans or the environment.
EFUP = 10 for Short Use Products
EFUP = 20 for Medium Use Products
This product consists of devices that may contain mercury,
which must be recycled or disposed of in accordance with
local, state, or country laws.
(Within this system, the backlight lamps in the monitor and the
Touch Panel display, contain mercury.)
Loading prohibited
Section 1-2 - Important Conventions
25, 2014)
UNE
LOGIQ™ S7 E
XPERT
S
ERVICE
LOCATION
various
rear of system at mains switch
Adjacent to On-Off/Standby switch left
below the Control panel.
rear of system at mains switch
rear of system at mains switch
(on primary power supply - RTN)
rear of system at mains switch
(on primary power supply - RTN)
Rear side of the unit
on the plug of each probe
Rear side of the unit
on the plug of each probe
Rear side of the unit
not visible:
- below the cover on read side of Monitor
- on rear side of the Touch Panel
at top cover of the system
