MEMORY CHANNEL PROGRAMMING

■ General description

The Memory mode is very useful to quickly select of-
ten-used operating settings.
The transceiver has 500 regular memory channels,
50 scan edge channels (25 pairs) and 4 call channels.
Also, 26 memory banks, A to Z, can be used to store
groups of operating channels, and so on. Up to 100
channels can be assigned to a bank.

D Memory channel contents

The following information can be programmed into
memory channels:
• Operating frequency
• Operating mode
• Duplex direction (DUP+/DUP–) with a frequency
offset
• Subaudible tone encoder, tone squelch or DTCS
squelch ON/OFF
• Subaudible tone frequency, tone squelch frequency
or DTCS code with polarity
• Scan skip setting
• Memory bank
• Memory name
• Tuning step
• UR Station call sign
• R1/R2 call sign
• Digital Call sign squelch or Digital code squelch ON
or OFF
• Digital code
NOTE: Memory data can be erased by static elec-
tricity, electric transients, and other causes. In addi-
tion, they can be erased by a malfunction and during
repairs. Therefore, we recommend that memory data
be backed up or be saved to a microSD card or to a
PC.
• The microSD card is not available from Icom. Purchase a
microSD card to meet your needs.
• The CS-51 cloning software that is included on the sup-
plied CD can also be used to backup the memory data.
• The optional OPC-2218LU is required to connect the
transceiver and a PC.
12-2
