16
MENU SCREEN
Menu items and Default settings (Continued)
■
NOTE: The default settings shown below are for the USA version.
The default settings may differ, depending on your transceiver version.
In this item, set other options.
Function
Power Save
Monitor
Dial Speed-UP
Auto Repeater
Remote MIC Key
During RX/Standby
During TX
Key Lock
PTT Lock
Busy Lockout
Time-Out Timer
Active Band
MIC Gain (Internal)
MIC Gain (External)
Data Speed
VOX VOX
VOX Level
VOX Delay
VOX Time-Out Timer
Headset Select
CI-V CI-V Address
CI-V Baud Rate
CI-V Transceive
RANGE OR VALUE (Default is shown in bold)
OFF, Auto (Short), Auto (Middle) or Auto
(Long)
Push or Hold
OFF or ON
OFF or ON (DUP), ON (DUP,TONE)
[A]:BAND [B]:VFO/MR [J]:UP [K]:DOWN
[A]:T-CALL [B]:– [J]:– [K]:–
Normal, No SQL, No VOL or ALL
OFF or ON
OFF or ON
OFF, 1min, 3min, 5min, 10min, 15min or
30min
Single or All
1~2~4
1~2~4
4800bps or 9600bps
OFF or ON
1~5~10 or OFF
0.5sec, 1.0sec, 1.5sec, 2.0sec, 2.5sec or
3.0sec
OFF, 1min, 2min, 3min, 4min, 5min, 10min
or 15min
HS-95 or Other
01~86~DF
300, 1200, 4800, 9600, 19200 or Auto
OFF or ON
16-12
DESCRIPTIONS
Selects the Power Save options to re-
duce current drain and conserve bat-
tery power.
Selects the [SQL] monitor function
method.
Turns the dial speed acceleration ON
or OFF.
Turns the Auto Repeater function ON
or OFF.
Selects the key function to be used
while receiving or in the standby mode.
Selects the key functions to be used
while transmitting.
Selects the key lock type when the Key
Lock function is turned ON.
Turns the PTT Lock function ON or
OFF.
Turns the Busy Lockout function ON or
OFF.
Selects the Time-Out Timer time op-
tions.
Allows continuous frequency selection
across all bands by rotating [DIAL].
Sets the internal microphone sensitiv-
ity to suit your preference.
Sets the external microphone sensitiv-
ity to suit your preference.
Selects the data transmission speed for
low-speed communication, or between
the [DATA] jack and external modules
like a GPS receiver, and so on.
Turns the VOX function ON or OFF.
Sets the VOX gain level.
Sets the VOX Delay time.
Sets the VOX Time-Out Timer to pre-
vent an accidental prolonged transmis-
sion.
Selects the headset type to be used for
the VOX function to limit the maximum
audio output level to protect the head-
set speaker.
Sets the transceiver's unique CI-V
hexadecimal address code.
Sets the CI-V code transfer speed.
Turns the CI-V Transceive function ON
or OFF.
