16
MENU SCREEN
GPS items (Continued)
■
GPS Position (Continued)
[MY] screen (MY Position)
Compass* Your direction
Latitude Your latitude
Longitude Your longitude
Shows the grid locator based on the latitude and longitude
GL
of your position.
ALT Your own altitude
SPEED Your speed over ground
TIME Current time received from the GPS
COURSE Your direction heading
When "Manual" is selected in the GPS Select item, the screen shows only latitude,
longitude, altitude, GL (Grid locator), and time (internal clock).
[RX] screen (Received position of the other station)
Compass* The caller's direction from your position
Latitude The caller's latitude
Longitude The caller's longitude
Shows the grid locator based on the latitude and longitude
GL
of the caller's position.
ALT The caller's altitude
DST The caller's distance from your position
Call sign The caller's call sign
SSID The caller's SSID (GPS-A only)
COURSE The caller's direction over ground
SPEED The caller's speed
GPS Time Stamp The time data that the caller acquires the position data.
GPS-A Symbol The caller's GPS-A Symbol
Nothing is displayed when No position data is received on your transceiver.
[MEM] screen (GPS memory alarm position)
Compass* GPS Memory channel's direction from your position
Latitude GPS Memory channel's latitude
Longitude GPS Memory channel's longitude
Shows the grid locator based on the latitude and longitude
GL
of GPS Memory channel's.
DST GPS Memory channel's distance from your position
GPS memory name* Shows the selected GPS memory name
[ALM] screen (GPS alarm position)
Compass* GPS Alarm area's direction from your position
Latitude GPS Alarm area's latitude
Longitude GPS Alarm area's longitude
Shows the grid locator based on the latitude and longitude
GL
of GPS Alarm area's.
DST GPS Alarm area's distance from your position
Shows "OFF," "RX," GPS memory group name or GPS
GPS Alarm*
memory name specified for the GPS alarm function.
*These items can be selected in the QUICK MENU screen.
16-35
