16
MENU SCREEN
RX History items (Continued)
■
To display the RX record contents
Push D-pad( ) to select the desired RX History number "RX01" to "RX50,"
q 
and then push D-pad(Ent).
Push D-pad( ) to switch the RX History contents screen.
w 
• When the received call includes GPS position data, it is displayed after RX
TIME.
• To register the caller station call sign, GPS information, or repeater call sign, push
D-pad() to show the desired contents, and then push [QUICK]
Push [MENU] to exit the MENU screen.
e
Contents of the RX history
Shows the call sign of the caller station and any note programmed
CALLER* 1
after the call sign.
CALLED* 1 Shows the call sign of the called station.
Shows the call sign of the repeater that was accessed by the
caller station.
RXRPT1* 1, * 2
If it was a call through a gateway and the internet, this item dis-
plays the gateway repeater call sign of your local area repeater.
RXRPT2* 1, * 2 Shows the call sign of the repeater you received the call from.
MESSAGE Shows any message included in the received call, if programmed.
RX TIME Shows the date and time the call was received.
COMPASS* 3 Shows the direction from your position to the caller station.
LATITUDE Shows the Latitude position of the caller station.
LONGITUDE Shows the Longitude position of the caller station.
Shows the latitude and longitude position data in a short string
GL(Grid Locator)
of characters.
Shows the altitude of the caller station,
ALTITUDE The altitude unit can be set to either the meter or feet/mile format
in the GPS menu.
DISTANCE* 3 Shows the distance between you and the caller station.
GPS-A SYMBOL Shows a GPS-A symbol of the caller station. (GPS TX mode: GPS-A)
Shows the APRS
"-0," "-1" to" -15," "-A" to " -Z")
SSID
when the caller station's GPS TX mode is set to "GPS-A" to assist
identifying the caller station.
COURSE Shows the course of the caller station.
Shows the speed the caller station is moving at.
SPEED The speed unit can be set to the km/h, mph or knots format in
the GPS menu.
GPS Time Stamp The time data that the caller acquires the position data.
Shows the GPS message or GPS-A comment included in the
GPS MESSAGE
position data of the received call.
* 1 These items show the name under the call sign, if programmed.
* 2 "FREQUENCY" appears instead of these items when the call was not through a
repeater (Simplex call), to show the frequency that was used.
3
* If you have no position data, these items are not displayed.
16-51
® based SSID (Secondary Station Identifier:
.
