16
MENU SCREEN
Voice Memo items (Continued)
■
NOTE:
• The folder name is automatically created, as shown in the example be-
low: Recording date : 2012/9/1
Folder name
• The file name is automatically created, as shown in the example below:
Recording date
File name
• The voice audio is recorded onto a microSD card, and saved in the "wav"
format.
The recorded voice audio can also be played back with a PC.
The extension, "wav," is not displayed on the transceiver's screen.
REC Mode
Voice Memo > QSO Recorder > Recorder Set > REC Mode (REC Mode)
Records both the transmitted and received audio as the default setting.
• TX&RX : Records both the transmitted and received voice audio.
• RX Only: Records only the received voice audio.
When transmitted while recording
When "OFF" is selected in File Split, the recording is paused. After finishing
the transmission, the recording resumes.
When "ON" is selected in File Split, a new file is automatically created, and
the transmitted voice audio is recorded into the new one.
RX REC Condition
Voice Memo > QSO Recorder > Recorder Set > RX REC Condition (RX REC
Condition)
Select whether or not the squelch status affects the RX voice audio record-
ing.
• Always : The transceiver always records the RX voice audio regard-
less of the squelch status.
• Squelch Auto : The transceiver records the RX voice audio only when a
signal is received (the squelch is opened).
When the squelch closes while recording, the recording will
continue for 2 seconds, and then pause.
When "ON" is selected in File Split, and if the squelch either opens or
closes while recording, a new file is automatically created.
16-23
: 20120901
: 2012/9/1 15:30:00
: 20120901_153000
(Default: Squelch Auto)
(Default: TX&RX)
