16
MENU SCREEN
Menu items and Default settings (Continued)
■
NOTE: The default settings shown below are for the USA version.
The default settings may differ, depending on your transceiver version.
In this item, set the GPS options.
GPS
GPS Set
GPS Select
Power Save (Internal GPS)
Manual Position
GPS Indicator
Position Format
Altitude/Distance Units
Speed Units
GPS Out
GPS Information
GPS Position
GPS Memory
GPS Alarm
Alarm Select
Alarm Area (Group)
Alarm Area (RX/Memory)
GPS Logger
GPS Logger*
Record Interval
<<GPS Logger Only>>
* Be sure to insert the microSD card into the
transceiver before selecting these items.
RANGE OR VALUE (Default is shown in bold)
OFF, Internal GPS, External GPS
or Manual
OFF, 1min, 2min, 4min, 8min or Auto
OFF or ON
ddd˚mm.mm' or ddd˚mm'ss"
m or ft/ml
km/h, mph or knots
OFF or ON
OFF, RX, Group or Memory
0'05"/0.08'~0'15"/0.25'~
59'59"/59.99'
Limited, Extended or Both
OFF or ON
1sec, 5sec, 10sec, 30sec or 60sec
16-7
DESCRIPTIONS
Selects the GPS receiver that the trans-
ceiver receives its position data from.
Selects the internal GPS receiver power
save function.
Manually enter your current position.
Turns the GPS indicator ON or OFF.
Selects position format to display the po-
sition.
Selects units to display the distance and
altitude.
Selects units to display the speed.
Turns the output of GPS information from
the internal GPS receiver to the [DATA]
jack ON or OFF.
Displays the received GPS information.
Displays your position, RX station, GPS
memory and Alarm positions.
Shows the GPS memory contents.
Select the target for the GPS alarm func-
tion.
Enter the GPS alarm active range.
Select the GPS alarm active range.
Turns the GPS logger function ON or OFF,
to store your route as you move.
Selects the GPS Logger function record
interval.
Turns ON the GPS logger function with
the transceiver in the Sleep mode.
(Continued on the next page.)
